Pioneer® Diamante Pro Series 24,000 BTU 19 SEER2 Ductless Mini Split Air Conditioner Inverter Heat Pump 230V with 16 Ft. Full Set Kit

Name: Powerful 24,000 BTU Pioneer Mini Split Heat Pump
SKU: WYT024GLFI19RL
Price: 1308.00 USD
Availability: InStock

Original price was: $1,699.00.Current price is: $1,308.00.

+ Free Shipping

Discover year-round comfort with the Pioneer Diamante Pro Series Ductless Mini Split Heat Pump System,
Model WYT018GLFI19RL

Offering 18,000 BTU of power and a high SEER2 rating of 19, this system ensures energy-efficient operation while maintaining ideal indoor temperatures. Designed for a 230V power supply, it includes a complete 16 Ft. kit for easy and seamless installation. The R410A Pre-Charged Outdoor Unit supports refrigerant lines up to 25 ft. per circuit. With copper tubing and communication wiring kits neatly packaged in separate boxes, this Pioneer system is both practical and efficient. It arrives in two cartons, delivering superior cooling and heating for residential or small commercial use.

SKU: WYT024GLFI19RL Categories: 24,000 BTU Ductless Mini Split Air Conditioner Heat Pumps, Single Zone Mini Split Air Conditioners Tags: 19 SEER, 230v, 24000 BTU, Diamante Pro, heat pump, mini split, Pioneer, wifi ready Brand: Pioneer

Summary

High Efficiency Diamante Pro Ductless Mini Split Heat Pump System
Cooling capacity: 24,000 BTU/H with 19 SEER2 / 10.0 EER2 efficiency
Heating capacity: 24,400 BTU/H with 8.5 HSPF2 / 3.21 COP2 efficiency
Voltage: 208~230V, 60Hz, 1Ph
High Wall Mounted Air Conditioning & Heating System
Variable Speed DC Inverter Operation Mode
Low Ambient Unit (-13°F)
AHRI Estimated Annual Operating Costs:
- Cooling: $176.00
- Heating: $516.00

Features

Dual Swing
Dual Drainage
Low Noise
High Efficiency

What’s Included

Indoor Unit
Outdoor Unit
Wireless Remote Control (with wall holder and batteries)
16 Ft. Copper Lines
16 Ft. Electrical Wire
10 Ft. Drain for indoor/outdoor
Wall Passage Sleeve
Putty for Wall Hole
Leak Guard Sealer
Wrapping Tape
Installation Manual
User’s Manual

Warranty Information

5 years Warranty for Parts
5 years Warranty for Compressor

Performance Data

Power Supply: 208~230V, 60Hz, 1Ph
Cooling Rated Capacity: 24,000 BTU/h
Cooling Capacity Range: 7,200~26,400 BTU/h
Cooling SEER2: 19.0 BTU/W.h
Cooling EER2: 10.0 BTU/W.h
Heating Rated Capacity: 24,400 BTU/h
Heating Capacity Range: 7320~26,840 BTU/h
Heating HSPF2 (Region IV/V): 8.5 / 7.0 BTU/W.h
Heating C.O.P.2 (47°F/5°F): 3.21 / 1.75 W/W
Refrigerant Type: R410A/50.1 oz.
Suitable Area: 550~1000 Sq.F

Indoor Unit Data

Part Number: WT024GLFI19HLE
Air Flow (Hi/Med/Lo): 847 / 700 / 641 CFM
Sound Level (Hi/Med/Lo): 48 / 43 / 38 dB(A)
Net Dimensions (WDH): 46-5/8 x 10-1/4 x 13-3/8 Inches
Carton Dimensions (WDH): 49-3/4 x 13-1/4 x 16-1/2 Inches
Net / Gross Weight: 37.5 / 46.3 lbs

Outdoor Unit Data

Part Number: YN024GLFI19RPE
Breaker Needed: 20A (double-pole)
Sound Level: 58.0 dB(A)
Net Dimensions (WDH): 33-1/4 x 15 x 27-1/2 Inches
Carton Dimensions (WDH): 37-3/4 x 17 x 29-1/2 Inches
Net / Gross Weight: 95.9 / 107.3 lbs

MANUALS & DOCUMENTS

Specifications

User & Installation Manual

Service Manual

AHRI Certificate

Energy Guide

Brand	Pioneer
